Monel K500 Flanges

ANSI B16.5 Alloy K500 Ring Type Joint Flanges, Monel K500 Industrial Flanges, Monel K500 Nippo Flanges, UNS N05500 Pipe Flanges, Alloy K500 Blind Flanges, Monel K500 Screwed Flanges Manufacturer in India.

ASME SB564 Alloy K500 Lap Joint Flange, ASTM B564 Monel K500 Threaded Flanges, Monel K500 Slip On Flanges, Monel DIN 2.4375 Socket Weld Flanges, Monel K500 Nippolet Flanges Suppliers in India.

We are Manufacturer, Supplier & Exporter of Monel K500 Flanges, which is further virtually nonmagnetic, even at quite low temperatures. Monel Alloy K500 Flanges is a precipitation-hardenable nickel-copper alloy that combines the excellent corrosion resistance characteristic of Monel Alloy K500 Flanges with the added advantage of greater strength and hardness. Monel k-500 is a nickel-copper alloy with the same corrosion resistance and characteristics as the monel 400. The monel k-500 has a greater strength and hardness then the 400, as a result of added aluminum and titanium. These flanges are widely used in various application industries like Chemicals, Fats, & Fertilizers, Sugar Mills & Distilleries, Cement Industries, Ship Builders, Paper Industries etc.

Known for their improved workability under cryogenic temperatures, with a rigidity of 160 ksi and a superb dimensional security are variables that add to the unwavering quality of UNS N05500 Monel K500 Socket Weld Flanges. WNR 2.4375 Flanges is a nickel alloy, prized for its strength and ability to resist corrosion. The applications of UNS N05500 Flanges include crude petroleum stills, gasoline and fresh water tanks, marine fixtures and fasteners, and chemical processing equipment. Grain growth of Monel K500 Socket Weld Flanges becomes fairly rapid above 1800 Degree F, and if a fine-grained structure is desired heating time should be kept to a minimum at these higher temperatures.

Specification

Grade	Monel K500 | UNS N05500
Standard	ASTM B564, ASME SB564
Dimensions	ANSI / ASME B16.5, B16.47 Series A & B, B.16.48, BS4504, BS10, DIN, EN-1092, MSS SP44
Size	1/2"NB - 60"NB
Class / Pressure Rating	150 Class, 300 Class, 718 Class, 900 Class, 1500 Class, 2500 Class, PN6, PN10, PN16, PN25, PN40, PN64, etc.
Form	Slip on Flanges (SORF), Threaded Flanges, Weld neck Flanges (WNRF), Blind Flanges, Socket weld Flanges, Lap Joint Flanges, Ring Type Joint Flanges, Spectacle Blind Flanges, Spacer Ring Flanges, Long weld Neck Flanges, Nipo Flange, Nipolet Flanges, Plate Flanges, Flat Flange, Orifice Flanges, Forged Flanges
Flange Face Type	Flat Face (FF), Raised Face (RF), Ring Type Joint(RTJ)

Grade Specification

STANDARD	WERKSTOFF NR.	UNS
Monel K500	2.4375	N05500

Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni
Monel K500	0.25 max	1.5 max	0.5 max	0.010 max	27.00 – 33.00	0.5 – 2	63.00 min

Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Monel K500	8.44 g/cm3	1350 °C (2460 °F)	Psi – 160000 , MPa – 1100	Psi – 115000 , MPa – 790	20 %
